CORE IDENTIFICATION

Cores shall be identified by different colouring of XLPE insulation by adopting the following scheme

1 Core	Red / Black / Yellow / Blue
2 Core	Red and Black
3 Core	Red, Yellow and Blue
3 1/2 Core	Red, Yellow, Blue, and reduced neutral core in Black
4 Core	Red, Yellow, Blue and Black
5 Core	Red, Yellow, Blue, Black and Grey

Where the number of cores exceeds 5, two adjacent cores are blue for reference and yellow for direction in each layer. The remaining cores in each layer are grey.

Note : Based Specific request we can also provide Core numbering for Control cables.

Cable Code : The following shall be used for designating the cable.

Constituents	Code Letter
Aluminium Conductor	A
XLPE Insulation	2X
Steel round wire armour	W
Steel strip armour	F
Steel double round wire armour	WW
Steel double strip armour	FF
PVC outer sheath	Y
Aluminium Wire armour	Wa
Aluminium Conductor, XLPE Insulated Armoured Cable	A2XWY/A2XFY
Aluminium Conductor, XLPE Insulated & PVC Sheathed Cable	A2XY
Copper Conductor, XLPE Insulated Armoured Cable	2XWY/2XFY
Copper Conductor, XLPE Insulated & PVC Sheathed Cable	2XY

Special Properties & Variants on request:

• Flame Retardent (FR) I Fire Retardant Low Smoke (FRLS) I Low Smoke Zero Halogen (FR-LSZH) Sheath.
• With Tinned Copper Conductor./li>
• UV Resistant Compound.

Standard Packing length will be 100 / 250 / 500 /1000± 10 % metres in drums.
